OEM / REF: SW180-24SKU: pilotpart722140
24 Volt Contactor SW180-24 for Yamaha Golf Cart is a Other Parts replacement part indexed for Part Number and Yamaha Golf Cart. Match OEM part number SW180-24 and confirm fitment for Yamaha Electrical Parts before ordering.
This Other Parts is indexed for Part Number; Yamaha Golf Cart. Compare reference number SW180-24 against the label on your existing Yamaha component before ordering.
Before checkout, compare OEM part number SW180-24, connector layout, mounting position, and machine serial number. For high-value or fitment-sensitive parts, submit the fitment form below so support can verify the match.
| Details | Single Pole, Single Throw, Normally Open, Magnetic Blowouts |
|---|---|
| Rated Current | 200 Amps |
| Voltage | 24V |
| Coil Power | 11 to 14W |
| Rated Voltage of Contact Circuit | 6 to 80 Volts DC |
| Dielectric Voltage Strength | 50Hz 1000V AC 1min |
| Current Volt Drop of Main Contact at 100A | Not above 80mV |
| Operating time, Contact Makes & Contact Brakes | 30ms |
| Part Number | SW180-24, SW18024 |
Match the OEM or reference number first, then verify machine model, engine model, serial number, connector layout, mounting points, and old part photos.
Yes. Send the old part number, machine plate, and photos through the fitment inquiry form. Support can review possible replacements or alternatives.
Products are indexed as replacement parts unless explicitly marked otherwise. Always compare reference numbers and confirm fitment before purchase.
