In StockNew Alternator AM877740 1002114530 AND0197 40052067 Replacement For John Deere Tractors Skid Steer Yanmar Loader 317 320 675/B 3235 455 F1145 755 756 855 856 955 XUV850D
Click to view full image
For John DeereAlternator

Alternator AND0197 for John Deere Yanmar 3T72 12V (STD.) Engine

OEM / REF: AND0197SKU: pilotpart388254

New Alternator AM877740 1002114530 AND0197 40052067 Replacement For John Deere Tractors Skid Steer Yanmar Loader 317 320 675/B 3235 455 F1145 755 756 855 856 955 XUV850D is a Alternator replacement part indexed for John Deere 3235 · Yanmar engineS W/Denso ALT. and John Deere 455 · Yanmar 3T72 12V (STD.) · 1996-1995,...

Stock
In stock
Condition
New
Fitment
John Deere Engine Spare Parts
Category
Alternator
  • Fitment support before you order
  • Worldwide delivery options

Alternator Description

This Alternator is indexed for John Deere 3235 · Yanmar engineS W/Denso ALT.; John Deere 455 · Yanmar 3T72 12V (STD.) · 1996-1995; John Deere 430 · Yanmar 3TNA72 22HP Dsl · 1984-1991; John Deere 7200 · Yanmar 26.4HP Dsl. Compare reference number AND0197 against the label on your existing John Deere component before ordering.

Additional cross references on file: 40052067, AM877740, 27060-78001. If your machine plate shows a different number, submit a fitment inquiry with photos before checkout.

Applications

  • John Deere 3235 · Yanmar engineS W/Denso ALT.
  • John Deere 455 · Yanmar 3T72 12V (STD.) · 1996-1995
  • John Deere 430 · Yanmar 3TNA72 22HP Dsl · 1984-1991
  • John Deere 7200 · Yanmar 26.4HP Dsl
  • John Deere F1145 · Yanmar 3TN75/3TNE78A W/Denso ALT. · 1992-1994
  • John Deere F925 · Yanmar 3TNA72 W/Denso ALT. · 2001-2007
  • John Deere F935 · 3029D · 1986-2007
  • John Deere 317 · JD 4024T 57HP engine Denso system · 2005-2011
  • John Deere 320 · JD 4024T 62HP engine Denso system · 2005-2011
  • John Deere 675 · Yanmar 4TNA82 · 1987-1989
  • John Deere 675B · Yanmar 4TNA82 · 1987-1994
  • John Deere 425 · 2 Cyl. 0.62L 617cc 38cid · 1993-1997
  • John Deere 425 · Kawasaki FD620D · 1993-2007
  • John Deere 445 · 2 Cyl. 0.62L 617cc 38cid · 1993-1997
  • John Deere 445 · Kawasaki FD620D · 1993-2007
  • John Deere 748 · Yanmar 24HP Dsl
  • John Deere X495 · 3029D · 1986-2007
  • John Deere X495 · Yanmar 24HP Dsl
  • John Deere X595 · Yanmar 24HP Dsl
  • John Deere X740 · Yanmar 24HP Dsl
  • John Deere X744 · Yanmar 24HP Dsl
  • John Deere X748SE · Yanmar 24HP Dsl
  • John Deere X749 · Yanmar 24HP Dsl
  • John Deere 6 x 4 · Yanmar 3TNA72 18HP Dsl · 1988-1995
  • John Deere 655 · Yanmar 3T72 Dsl · 1986-2007
  • John Deere 755 · Yanmar 3T72 from SER. #0030104 · 1995-1993
  • John Deere 756 · Yanmar 3T72 from SER. #0030104 · 1990-1986
  • John Deere 855 · Yanmar 3T72 from SER. #009849
  • John Deere 856 · Yanmar 3T72 from SER. #009849 · 1990-1986
  • John Deere 955 · Yanmar 3TN84/3T72 · 1989-1990
  • John Deere 3005 · Yanmar 27.5HP Dsl · 2008-2012
  • John Deere 4005 · Yanmar 41.5HP Dsl
  • John Deere 4010 · Yanmar 18.5HP DSL W/Denso 40A alternator · 2002-2005
  • John Deere 4110 · Yanmar 20HP DSL W/Denso 40A alternator · 2002-2005
  • John Deere 1600 · Yanmar 51HP Dsl · 2005-2011
  • John Deere 1620 · 3 Cyl. 1.5L 1496cc 91cid · 1999-2003
  • John Deere 3365 · 3 Cyl. 1.36L 1363cc 83cid
  • John Deere 3215B · 3 Cyl. 1.2L 1204cc 73cid · 1994-2000
  • John Deere 3225B · 220 32HP Dsl · 2002-2006
  • John Deere 3225C · 3 Cyl. 1.5L 1496cc 91cid · 2004-2009
  • John Deere 3235B · 3 Cyl. 1.5L 1496cc 91cid · 2004-2006
  • John Deere 3235C · 3 Cyl. 1.5L 1496cc 91cid · 2004-2009
  • John Deere 3245C · 3 Cyl. 1.5L 1496cc 91cid · 2004-2006
  • John Deere 997 · Yanmar 30HP Dsl
  • John Deere 6 x 4 · Yanmar 3TN66 Dsl · 1995-2007
  • John Deere A1 Military · Yanmar 3TN66C 18HP Dsl / 3TNV70 20HP Dsl
  • John Deere HPX · Yanmar 3TNE68 20HP Dsl
  • John Deere TH 6x4 · 854cc Dsl · 2010-2011
  • John Deere XUV 850D 4x4 · Yanmar 3TNV70 24HP Dsl
  • John Deere
  • John Deere
  • John Deere
  • John Deere

Specifications

Voltage12V
Amperage40A
DesignIR/IF
RotationCW
Pulley classV1
Note1/2 in. Belt
Part NumberAND0197, 40052067, 400-52067, AM877740, 27060-78001, 27060-78001-71, 2706078001, 270607800171, 1002114530, 1002110531, 1002111660, 1002111661, 100211166 , 1002114490, 1002114528, 1002114531, 1002114560, 1002114610, 1002114690, 100211-4530, 100211-4531, 119620-77201, 119620-77202, 12188, 12188N

Fitment Notes

Brand or application signal
John Deere Engine Spare Parts
Product family
Alternator
System category
Engine Spare Parts > Engine Auxiliary Components > Alternator
Recommended verification
OEM number, engine model, serial number, old part photos, and dimensions.
