OEM / REF: 82016158SKU: pilotpart125488
A/C Compressor 82016158 for CASE Tractor MXM120 MXM130 MXM140 MXM155 MXM175 MXM190 is a Air Conditioning Compressor replacement part indexed for Case MXM120 and Case MXM130, with 3 application records on file. Match OEM part number 82016158 and confirm fitment for CASE HVAC Parts before ordering.
This Air Conditioning Compressor is indexed for Case MXM120; Case MXM130; Case MXM140; Case MXM155. Compare reference number 82016158 against the label on your existing CASE component before ordering.
Additional cross references on file: 81866263, 82008688, 82002069. If your machine plate shows a different number, submit a fitment inquiry with photos before checkout.
| Compressor Family | SD7H15 |
|---|---|
| Compressor Mount Type | Ear |
| Rotation Direction | CW |
| Cylinder Head | JE |
| Port Angle | Vertical |
| Head Port Style | O-Ring |
| Head Port Discharge Size | 3/4" Male Threaded |
| Head Port Suction Size | 7/8" Male Threaded |
| Clutch Diameter | 119 mm ~ 4 and 11/16 inches |
| Clutch Style | Dust Cover |
| Belt Type | Serpentine |
| Number of Grooves | 8 |
| Voltage | 12V |
| Coil Connector | 1 Wire Male Bullet |
| Coil Position | 12 O'clock |
| Oil Type | SP15 or PAG 100 |
| Oil Qty | 135cc |
| Refrigerant | R134a |
| Part Number | 82016158, 81866263, 82008688, 82002069, 820161571, 87709786 |
Match the OEM or reference number first, then verify machine model, engine model, serial number, connector layout, mounting points, and old part photos.
Yes. Send the old part number, machine plate, and photos through the fitment inquiry form. Support can review possible replacements or alternatives.
Products are indexed as replacement parts unless explicitly marked otherwise. Always compare reference numbers and confirm fitment before purchase.
