How do I confirm pilotpart389304 fits my machine?

Compare the OEM or reference part number, machine model, engine model, and serial number. You can also submit a fitment inquiry before ordering.

In Stock

New 12V Starter Solenoid Replacement For 2001-2009 Chevy & GMC DIESEL 6.6 Duramax V8 Silverado Sierra LB7 LLY 97209548 97720446 S14-100DR S14-100E S14-101AR

For GMC Starter Motor

Starter Motor 336-1737A for GMC 6.6L/403CI V8 DIESEL Engine

Q: What part numbers are associated with this Starter Motor?

336-1737A, 97209548, 97720446, 890117630, S14-100, S14-100D, S14-100DR, S14-100E, S14-101, S14-101A, S14-101AR, S14-101B

OEM / REF: 336-1737ASKU: pilotpart389304

New 12V Starter Solenoid Replacement For 2001-2009 Chevy & GMC DIESEL 6.6 Duramax V8 Silverado Sierra LB7 LLY 97209548 97720446 S14-100DR S14-100E S14-101AR is a Starter Motor replacement part indexed for CHEVROLET C4500 KODIAK · 6.6L/403CI V8 DIESEL · 2003-2006 and CHEVROLET C5500 KODIAK · 6.6L/403CI V8 DIESEL · 20...

Stock: In stock
Condition: New
Fitment: GMC Engine Spare Parts
Category: Starter Motor

Fitment support before you order
Worldwide delivery options

In stock — ready to order

$69.13USD/EA

~~$6,599.00~~Save 99%

Estimated delivery by quantity

Estimated delivery windows
Qty	Estimated delivery
1	Oct 22 – Oct 29
10	Oct 20 – Oct 27
50	Oct 18 – Oct 25

Estimates from today; confirm exact lead time before payment.

Quantity

Confirm fitment before ordering →

Lead times can vary by freight route and customs. Contact support for expedited shipping.

Starter Motor Description

This Starter Motor is indexed for CHEVROLET C4500 KODIAK · 6.6L/403CI V8 DIESEL · 2003-2006; CHEVROLET C5500 KODIAK · 6.6L/403CI V8 DIESEL · 2001-2006; CHEVROLET EXPRESS 2500 · 6.6L/400CI V8 DIESEL; CHEVROLET EXPRESS 3500 · 6.6L/400CI V8 DIESEL. Compare reference number 336-1737A against the label on your existing GMC component before ordering.

Additional cross references on file: 97209548, 97720446, 890117630. If your machine plate shows a different number, submit a fitment inquiry with photos before checkout.

Part Numbers and Cross References

336-1737A 97209548 97720446 890117630 S14-100 S14-100D S14-100DR S14-100E S14-101 S14-101A S14-101AR S14-101B

Applications

CHEVROLET C4500 KODIAK · 6.6L/403CI V8 DIESEL · 2003-2006
CHEVROLET C5500 KODIAK · 6.6L/403CI V8 DIESEL · 2001-2006
CHEVROLET EXPRESS 2500 · 6.6L/400CI V8 DIESEL
CHEVROLET EXPRESS 3500 · 6.6L/400CI V8 DIESEL
CHEVROLET KODIAK · 6.6L/400CI V8 DIESEL · 2003-2005
CHEVROLET V SERIES PICKUPS · 6.6L/400CI V8 DIESEL · 2001-2006
GMC C4500 TOPKICK · 6.6L/403CI V8 DIESEL · 2003-2006
GMC C5500 · 6.6L/400CI V8 DIESEL · 2001-2005
GMC SAVANA 2500 · 6.6L/400CI V8 DIESEL
GMC SAVANA 2500 BASE · 6.6L/400CI V8
GMC SAVANA 3500 · 6.6L/400CI V8 DIESEL
GMC SAVANA 3500 BASE · 6.6L/400CI V8
GMC SIERRA 2500 HD BASE · 6.6L/400CI V8 · 2002-2005
GMC SIERRA 2500 HD BASE · 6.6L/403CI V8
GMC SIERRA 2500 HD SL · 6.6L/400CI V8 · 2001-2006
GMC SIERRA 2500 HD SLE · 6.6L/400CI V8 · 2001-2006
GMC SIERRA 2500 HD SLE · 6.6L/403CI V8
GMC SIERRA 2500 HD SLT · 6.6L/400CI V8 · 2001-2006
GMC SIERRA 2500 HD SLT · 6.6L/403CI V8
GMC SIERRA 2500 HD WT · 6.6L/400CI V8 · 2003-2006
GMC SIERRA 2500 HD WT · 6.6L/403CI V8
GMC SIERRA 3500 BASE · 6.6L/400CI V8 · 2002-2005
GMC SIERRA 3500 BASE · 6.6L/403CI V8
GMC SIERRA 3500 SL · 6.6L/400CI V8 · 2001-2006
GMC SIERRA 3500 SLE · 6.6L/400CI V8 · 2001-2006
GMC SIERRA 3500 SLE · 6.6L/403CI V8
GMC SIERRA 3500 SLT · 6.6L/400CI V8 · 2001-2006
GMC SIERRA 3500 SLT · 6.6L/403CI V8
GMC SIERRA 3500 WT · 6.6L/400CI V8 · 2004-2006
GMC SIERRA 3500 WT · 6.6L/403CI V8

Specifications

ITEM DESCRIPTION	SOLENOID
UNIT TYPE	HITACHI
VOLTAGE	12
LENGTH OF CAN	55MM
LENGTH OA	54
MOUNT TYPE	2 HOLE MOUNT
MOUNTING HOLE LOCATIONS	01:30, 07:30
OD BODY	52
TERMINAL BATTERY	M8 X 1.25
TERMINAL COUNT	3 TERM
TERMINAL MOTOR	M8 X 1.25
TERMINAL SWITCH	M5 X 0.8 POST (LH)
TERMINAL SWITCH POSITION	LEFT
THREADS MOUNTING	M6 X 1.0 THD
Part Number (DELCO)	336-1737A
Part Number (GENERAL MOTORS)	97209548, 97720446, 890117630
Part Number (HITACHI)	S14-100, S14-100D, S14-100DR, S14-100E, S14-101, S14-101A, S14-101AR, S14-101B, S14-101DAM, S14-103A, S14100, S14100D, S14100DR, S14100E, S14101, S14101A, S14101AR, S14101B, S14101DAM, S14103A, STR0023
Part Number (ISUZU)	8972095483, 8972095484, 897209-548-4
Part Number	DELCO: 336-1737A GENERAL MOTORS: 97209548, 97720446, 890117630 HITACHI: S14-100, S14-100D, S14-100DR, S14-100E, S14-101, S14-101A, S14-101AR, S14-101B, S14-101DAM, S14-103A, S14100, S14100D, S14100DR, S14100E, S14101, S14101A, S14101AR, S14101B, S14101DAM, S14103A, STR0023 ISUZU: 8972095483, 8972095484, 897209-548-4

Fitment Notes

Brand or application signal: GMC Engine Spare Parts
Product family: Starter Motor
System category: Engine Spare Parts > Engine Auxiliary Components > Starter Motor
Recommended verification: OEM number, engine model, serial number, old part photos, and dimensions.

Shipping & Returns

Availability: InStock
Shipping: Shipping quotes can be confirmed before payment for heavy or urgent orders.
Returns: Returns are easier when fitment is confirmed before ordering.
B2B support: Bulk, fleet, and repair-shop requests can be handled through the inquiry form.

Frequently Asked Questions

How do I confirm this part fits my machine?

Match the OEM or reference number first, then verify machine model, engine model, serial number, connector layout, mounting points, and old part photos.

Can I order if my part number is not listed?

Yes. Send the old part number, machine plate, and photos through the fitment inquiry form. Support can review possible replacements or alternatives.

Is this an OEM part?

Products are indexed as replacement parts unless explicitly marked otherwise. Always compare reference numbers and confirm fitment before purchase.
