OEM / REF: 130974RSKU: pilotpart123283
A/C Compressor 87519620 for CASE Tractor FARMALL 105N 105U 105V 60 65C 70 75C 80 85C 85N 90 95 is a Air Conditioning Compressor replacement part indexed for Case FARMALL 105N and Case FARMALL 60, with 3 application records on file. Match OEM part number 130974R and confirm fitment for CASE HVAC Parts before ordering.
This Air Conditioning Compressor is indexed for Case FARMALL 105N; Case FARMALL 60; Case FARMALL 65C; Case FARMALL 70. Compare reference number 130974R against the label on your existing CASE component before ordering.
Additional cross references on file: 87519620, C1106-7036T, 1706-7029. If your machine plate shows a different number, submit a fitment inquiry with photos before checkout.
| Voltage | 12V |
|---|---|
| Number of Grooves | 4 |
| Sanden Number | 8279, SD7H15-8279 |
| Compressor Family | SD7H15 |
| Style | Sealed Heavy Duty |
| Compressor Mount Type | Direct |
| Rotation Direction | CW |
| Cylinder Head | KG |
| Port Angle | Horizontal |
| Head Port Style | 3/4 X 7/8 Threaded Male Fittings |
| Clutch Diameter | 112 mm ~ 4 and 7/16 inches |
| Clutch Pulley Type | With Dust Cover |
| Belt Type | Serpentine |
| Coil Connector | 2 Wire |
| Coil Position | 12 O'clock |
| Oil Type | SP15 or PAG 100 |
| Oil Qty | 190cc |
| Refrigerant | R134a |
| Part Number (ACR) | 130974R |
| Part Number (FORD/NEW HOLLAND) | 87519620, C1106-7036T, 1706-7029, C11067036T, 17067029 |
| Part Number (FRIGAIR) | 9202.0247 |
| Part Number (HELLA) | 351128071 |
| Part Number (WEBASTO) | 82D0156250CA, 82D0156250MA |
| Part Number | ACR: 130974R FORD/NEW HOLLAND: 87519620, C1106-7036T, 1706-7029, C11067036T, 17067029 FRIGAIR: 9202.0247 HELLA: 351128071 WEBASTO: 82D0156250CA, 82D0156250MA |
Match the OEM or reference number first, then verify machine model, engine model, serial number, connector layout, mounting points, and old part photos.
Yes. Send the old part number, machine plate, and photos through the fitment inquiry form. Support can review possible replacements or alternatives.
Products are indexed as replacement parts unless explicitly marked otherwise. Always compare reference numbers and confirm fitment before purchase.
