In StockStarter Motor 12-098-01 12-098-03 128000-7480 for Toro 267-H 268-H 268-HE 269-H 270-H 270-HE Lawn and Garden Tractors Z Master Z118 Z150 Z153 Z222 Z252 Z253 Z255 Z256 Z286E Z320 Z355 ZTR Mowers
Click to view full image
For ToroStarter Motor

Starter Motor 0151747 for Toro Kohler 20HP Engine

OEM / REF: 0151747SKU: pilotpart726375

Starter Motor 12-098-01 12-098-03 128000-7480 for Toro 267-H 268-H 268-HE 269-H 270-H 270-HE Lawn and Garden Tractors Z Master Z118 Z150 Z153 Z222 Z252 Z253 Z255 Z256 Z286E Z320 Z355 ZTR Mowers is a Starter Motor replacement part indexed for Toro Multi Pro 1200 · Kohler 20HP · 2001-2011 and Toro Multi Pro 1250 · Koh...

Stock
In stock
Condition
New
Fitment
Toro Engine Spare Parts
  • Fitment support before you order
  • Worldwide delivery options

Starter Motor Description

This Starter Motor is indexed for Toro Multi Pro 1200 · Kohler 20HP · 2001-2011; Toro Multi Pro 1250 · Kohler 20HP · 2000-2011; Toro 266-H · Kohler 16HP · 1994-1996; Toro 267-H · Kohler 17HP · 1996-1998. Compare reference number 0151747 against the label on your existing Toro component before ordering.

Additional cross references on file: 017480, SND0007, ND128000-7480. If your machine plate shows a different number, submit a fitment inquiry with photos before checkout.

Applications

  • Toro Multi Pro 1200 · Kohler 20HP · 2001-2011
  • Toro Multi Pro 1250 · Kohler 20HP · 2000-2011
  • Toro 266-H · Kohler 16HP · 1994-1996
  • Toro 267-H · Kohler 17HP · 1996-1998
  • Toro 268-H · Kohler 16HP · 1994-1995
  • Toro 268-H · Kohler 18HP · 1999-2002
  • Toro 268-HE · Kohler 18HP · 2000-2003
  • Toro 269-H · Kohler 19HP · 1996-1998
  • Toro 270-H · Kohler 20HP · 1996-2002
  • Toro 270-HE · Kohler 20HP · 2000-2003
  • Toro 518xi · Kohler 18HP · 1998-2001
  • Toro 520xi · Kohler 20/22HP · 1998-2004
  • Toro 550 · Kohler 674cc
  • Toro Groundsmaster 120 · Kohler 20HP · 1996-2002
  • Toro Dingo 222 · Kohler 22HP · 1998-2001
  • Toro Dingo 322 · Kohler 22HP · 1999-2000
  • Toro Dingo TX-420 · Kohler 20HP · 2000-2004
  • Toro Workman 3100 · Kohler 23HP · 1994-2001
  • Toro Z Master Z118 · Kohler 18HP
  • Toro Z Master Z150 · Kohler 20HP · 1999-2001
  • Toro Z Master Z153 · Kohler 23HP
  • Toro Z Master Z222 · Kohler 20HP
  • Toro Z Master Z252 · Kohler 22HP
  • Toro Z Master Z253 · Kohler 23HP · 1999-2000
  • Toro Z Master Z255 · Kohler 25HP · 1998-2001
  • Toro Z Master Z256 · Kohler 26HP
  • Toro Z Master Z286E · Kohler 26HP
  • Toro Z Master Z320 · Kohler 20/25HP · 1997-1999
  • Toro Z Master Z355 · Kohler 20/25HP

Specifications

Voltage12V
Power0.6KW
Teeth9T
RotationCCW
Starter TypeDD
Part Number (Andre Niermann)0151747, 017480
Part Number (Arrowhead)SND0007, ND128000-7480
Part Number (Arrowhead Old)SND0219
Part Number (BBB HD)17628
Part Number (Carquest HD)17628S, 17628AS
Part Number (Denso)128000-7480, 228000-2640
Part Number (Denso Remanufactured)9722809-264
Part Number (Dixie Electric)S-8539, S-8538
Part Number (Excel)2940
Part Number (J & N Automotive)410-52050, 410-52050R
Part Number (John Deere)AM107631, AM108390, AM124993, AM131296
Part Number (Kohler)12-098-01, 12-098-03, 12 098 01, 12 098 03, 1209801, 1209803, 12-098-03S, 24-098-01, 24-098-01S
Part Number (Lester)17628
Part Number (MES - Marine Electric Suppliers)17628N, ME3500-NA
Part Number (NAPA HD)17628
Part Number (NAPA New HD)17628N
Part Number (NAPA Pro Series)17628
Part Number (New Holland)K0H2409801
Part Number (Remy Small Motor)RS41263
Part Number (Tisco)SND0007
Part Number (United Technologies)5174720-M030SM, SM51747
Part Number (Wilson)71016744
Part Number (Wilson HD New)91-29-5239N
Part Number (Wilson Heavy Duty)91-29-5239
Part NumberAndre Niermann: 0151747, 017480 Arrowhead: SND0007, ND128000-7480 Arrowhead Old: SND0219 BBB HD: 17628 Carquest HD: 17628S, 17628AS Denso: 128000-7480, 228000-2640 Denso Remanufactured: 9722809-264 Dixie Electric: S-8539, S-8538 Excel: 2940 J & N Automotive: 410-52050, 410-52050R John Deere: AM107631, AM108390, AM124993, AM131296 Kohler: 12-098-01, 12-098-03, 12 098 01, 12 098 03, 1209801, 1209803, 12-098-03S, 24-098-01, 24-098-01S Lester: 17628 MES - Marine Electric Suppliers: 17628N, ME3500-NA NAPA HD: 17628 NAPA New HD: 17628N NAPA Pro Series: 17628 New Holland: K0H2409801 Remy Small Motor: RS41263 Tisco: SND0007 United Technologies: 5174720-M030SM, SM51747 Wilson: 71016744 Wilson HD New: 91-29-5239N Wilson Heavy Duty: 91-29-5239

Fitment Notes

Brand or application signal
Toro Engine Spare Parts
Product family
Starter Motor
System category
Engine Spare Parts > Engine Auxiliary Components > Starter Motor
Recommended verification
OEM number, engine model, serial number, old part photos, and dimensions.

Shipping & Returns

Availability
InStock
Shipping
Shipping quotes can be confirmed before payment for heavy or urgent orders.
Returns
Returns are easier when fitment is confirmed before ordering.
B2B support
Bulk, fleet, and repair-shop requests can be handled through the inquiry form.

Frequently Asked Questions

How do I confirm this part fits my machine?

Match the OEM or reference number first, then verify machine model, engine model, serial number, connector layout, mounting points, and old part photos.

Can I order if my part number is not listed?

Yes. Send the old part number, machine plate, and photos through the fitment inquiry form. Support can review possible replacements or alternatives.

Is this an OEM part?

Products are indexed as replacement parts unless explicitly marked otherwise. Always compare reference numbers and confirm fitment before purchase.
